RB-A8-4
RBT
84774090
This Vacuum Thermoforming Machine for luggage is composed of a molding system, heating system, control system, and more. The operation of this suitcase making machine is divided into left and right stations. The left frame enters the middle heating furnace and is heated according to the set time, while the right frame can shape, pick, and place materials simultaneously. Then the right frame is moved into the middle heating furnace for heating according to the set time, alternating the cycle.
The Plastic Thermoforming Machine for luggage is equipped with laser distance measurement to control the plate at a certain distance, preventing it from falling after being heated for too long. This Vacuum Forming Machine for luggage also features a vacuum box to ensure sufficient vacuum capacity. The left and right forming stations are respectively equipped with devices such as blowing, primary small vacuum, secondary large vacuum, and demolding air blowing. A corresponding gate valve switch controls bubble blowing and small vacuum, with adjustable flow rate, ideal for processes like polycarbonate vacuum forming for 32 inch luggage.
This Suitcase Thermoforming Machine requires only the disassembly and installation of the mounting strip on the mold installation base plate to replace the mold, improving the speed of mold changes and ensuring the mold does not drop when the power is off. The mold can also be directly installed on the installation base plate. The fan cooling system of the left and right stations of this Full Automatic ABS PC Plastic Sheets Forming machine adopts four high-efficiency centrifugal fans, which can flexibly adjust the angle of the air outlet and accelerate the cooling and shaping process, thereby improving production efficiency.
The heating furnace part of this Dual Station Luggage Forming Machine is divided into an upper heating furnace and a lower heating furnace, adopting an independent pressure-regulating temperature control system for each. The upper heating furnace uses 122*122 honeycomb far-infrared heating bricks, while the lower heating section features densely arranged heating tubes, including four symmetrical heating tubes arranged horizontally. The heating furnace can automatically adjust to output different temperatures, compensating for temperature differences between the left and right stations.
The heating furnace on this suitcase machine can move left and right to preheat the mold. The machine offers both manual and automatic operation modes, making it suitable for operators of various proficiency levels. An infrared grating is installed at the loading and unloading positions to prevent the frame from falling and injuring the operator. The operation interface of this luggage making machine is user-friendly, allowing real-time adjustments to all parameters and featuring a recipe-saving function.
Furthermore, this machine plays a crucial role in the polycarbonate vacuum forming process, especially for 32 inch luggage. Its advanced features make it an essential part of the luggage production line, significantly enhancing the efficiency and quality of luggage manufacturing. This makes the Vacuum Thermoforming Machine a vital piece of equipment for any luggage manufacturing operation, including the production of ABS and PC plastic luggage shells.
NO. | Item | Model | |||
RB-A8- 1(20 inch) | RB-A8-2(24 inch) | RB-A8-3 （28 inch） | RB-A8-4（30/32 inch） | ||
1 | Dimension | 2863× 1700× 2520mm | 3187× 1755× 2520mm | 3500× 1966× 2630 mm | 3600×2266× 2630mm |
2 | Weight | 2000KG | 2350KG | 2600KG | 2800KG |
3 | Power Voltage | 3-380V( 3 phase 5 lines） | 3-380V(3 phase 5 lines） | 3-380V(3 phase 5 lines） | 3-380V(3 phase 5 lines） |
4 | Frequency | 50HZ | 50HZ | 50HZ | 50HZ |
5 | Total Power | 38KW | 50KW | 59KW | 59KW |
6 | Heating Power |
| 48KW | 56KW | 56KW |
7 | Heating brick spec | 120* 120/ 500W | 120* 120/ 500W | 120* 120/ 500W | 120* 120/ 500W |
8 | Heating tube spec | ∅ 22*/1.5KW | ∅ 22*/1.5KW | ∅ 22*/1.5KW | ∅ 22*/1.5KW |
9 | Spec of upper electric furnace | (inner)680*980*110mm | (inner)815* 1005*110mm | (inner)950* 1130*110mm | (inner)1039* 1241*110mm |
10 | Upper electric furnace (heating brick arrangement) | 5*7 | 6*8 | 7*8 | 7*9 |
11 | Spec of bottom electric furnace (brick) | ( inner) 680*980*45mm | ( inner)815* 1005*45mm | ( inner)946* 1035*45mm | ( inner)1039* 1241*45mm |
12 | Bottom electric furnace (heating brick arrangement) | 5*6 | 6*7 | 7*8 | 7*9 |
13 | Bottom furnace (heating tube arrangement) | 8+4+2 (Vertical ) | 10+4+2 （ Vertical） | 14+4+2 （ Vertical ） | 16+4+2 （ Vertical ） |
14 | Vacuum capacity | 0.2m³ | 0.3m³ | 0.35m³ | 0.4m³ |
15 | Vacuum pressure | -0.07~0.09MPA | |||
16 | Max Plastic Sheet Spec( L*W) | 830*610mm | 960*747mm | 960*885mm | 1085*885mm |
17 | Maximum mold size(L*W*H) | 600*420* 190mm | 690*510* 190mm | 780*600* 190mm | 840*640* 190mm |
18 | Maximum frame size(L*W) | 680*500mm | 780*600mm | 880*700mm | 1035*830mm |
19 | Sheet Material and Thickness | ABS 、PC etc；1-4mm | |||
20 | ABS case max. output (pcs /H) | 110 | 105 | 90 | 80 |
21 | PC case max. output(pcs /H) | 85 | 80 | 70 | 60 |
22 | Air pressure | 0.65~0.75 | |||
23 | Air consumption | 550L/MIN | 650L/MIN | 800L/MIN | 900L/MIN |
24 | Power spec | 3-380V+N+ PE | 3-380V+N+ PE | 3-380V+N+ PE | 3-380V+N+ PE |
25 | Power line spec | 4- 16mm²*1- 10mm² | 4- 16mm²*1- 10mm² | 4-35mm²*1- 16mm² | |
Configuration
No. | Item | Origin/Brand | Remark |
1 | Heating brick | Chinese | |
2 | Pneumatic element | Taiwan AirTAC | |
3 | Temperature control module | Shanghai Aoyi | Modular voltage adjustment |
4 | PLC | Xinje | |
5 | Touch Screen | Shenzhen Weinview | |
6 | Travel Switch,Induction Switch | Japan Omron | |
7 | Driving Motor | Shenzhen Yankong | Precision Stepping motor |
8 | Electrical element | France Schneider/Zhejiang Zhengtai |
35KW
